F-15 LED
An SMD LED spot for many applications. With its 17 SMD LEDs.
It ensures a homogeneous illumination.
In addition, it is pivotable and rotatable. It is available in warm or cold white.
Highlights
+ Thanks to 17 SMD LEDs homogeneous, glare-free illumination
+ Multivoltage (10 – 30V)
+ Optional nightlight variants available
+ Rotatable and swivelling
Please use the watchlist to send us your inquiry. Please indicate whether you are a private customer or a commercial customer. Private customers can also contact our dealers directly.
| SKU | Housing colour | Light colour | Night light | |
|---|---|---|---|---|
| 6390 | white | cool white | blue | Add to watchlist |
| 6391 | black | cool white | blue | Add to watchlist |
| 6392 | grey | cool white | blue | Add to watchlist |
| 6387 | white | warm white | no | Add to watchlist |
| 6393 | white | warm white | blue | Add to watchlist |
| 6388 | black | warm white | no | Add to watchlist |
| 6394 | black | warm white | blue | Add to watchlist |
| 6389 | grey | warm white | no | Add to watchlist |
| 6395 | grey | warm white | blue | Add to watchlist |
| 6396 | white | cool white | red | Add to watchlist |
| 6397 | black | cool white | red | Add to watchlist |
| 6398 | grey | cool white | red | Add to watchlist |
| 6384 | white | cool white | no | Add to watchlist |
| 6399 | white | warm white | red | Add to watchlist |
| 6400 | black | warm white | red | Add to watchlist |
| 6385 | black | cool white | no | Add to watchlist |
| 6386 | grey | cool white | no | Add to watchlist |
| 6401 | grey | warm white | red | Add to watchlist |
-
Housing colour
black, grey, grey, black, white, white
-
Light colour
cool white, cool white, warm white, warm white
-
Night light
blue, blue, no, no, red, red
-
Shape
round, round
-
Design
Recessed lighting fixture, Recessed lighting fixture
-
Power (watts)
2, 2
-
Switch
no, no
-
Protection class
IP40, IP40
-
CRI
>80, >80
-
Lifetime
L70 / 50.000 Std., L70 / 50.000 Std.
-
Dimmable
no, no
-
Material housing
Polycabonat, Polycabonat
-
Connection cable
200mm 0,5cm², 200mm 0,5cm²
-
CE Certified
yes, yes
-
Installation method
Clamps, Clamps
-
Diameter (mm)
75, 75
-
Mounting depth (mm)
18, 18
-
Mounting diameter (mm)
65, 65
-
Weight (grams)
60, 60
-
Features
Night light via 2nd positive line, Night light via 2nd positive line
-
Made in Germany
Ja, Ja
-
Voltage
10-30 Volt/DC, 10-30 Volt/DC
| Runder-SMD-LED-Einbauspot-dreh-und-schwenkbar-F-15 | Download |
